Olide-120B Commercial Swing Door Auto Opener, ADA Automatic Swing Operator with Exit Button and Fail Safety Electric Strike

  • $568.28
Shipping calculated at checkout.

Only 200 left!

Commercial Swing Door Auto Opener, ADA Automatic Swing Operator with Exit Button and Fail Safety Electric Strike

The ADA compliant automatic swing operator boasts a wide voltage range of 100-240V and features a fail safety electric strike. With the ability to automatically re-open when detecting objects in the door closing path, this opener offers convenience and safety. Plus, it can be operated remotely or manually with the option to turn off manual open.

Olide-120B automatic swing door opener

ADA Commercial Electric Swing Door Opener Features

  1. Wide Operating Voltage Range: The system is engineered to accommodate a wide voltage input, from 100 to 240 volts, making it versatile and adaptable to various power supply conditions. This ensures consistent operation across different regions with fluctuating voltage levels.
  2. Intelligent Obstacle Detection: Enhanced with smart sensors, the door system automatically re-opens if it encounters any obstacles along its closing path. This safety feature helps prevent accidents and ensures the protection of individuals as well as the door itself from damage.
  3. Dual-Mode Operation: Users have the best of both worlds with the ability to switch between automatic and manual modes. The manual open function can be enabled or disabled as required, providing flexibility in how the door is used and ensuring accessibility in all situations. (Push&Go function, when manual open the door, the motor remains engaged)
  4. Convenient Remote Access: Control of the automatic swing door is made effortless with the inclusion of a remote control system. This feature enables users to operate the door from a distance, adding a layer of convenience to everyday interactions.
  5. Secure Locking with Fail-Safety: Security is a paramount feature of the OlideSmart Door System, which incorporates a fail-safe electric strike lock. This means that the door remains securely locked when powered on, enhancing the overall security of the premises.

 Technical Specification

Voltage 110-220V AC+/-10%
Power Consumption 50W
Opening Time 3-7 sce.@90 degrees
Hold Open Time 1-30 sec. Adjustable
Max. Door Frame Depth

220mm/8.66"(with normal push arm)

330mm/13"(with extend push arm)

Door Width

Max. 1200mm / 47.2"  Min. 680mm / 26.77"(pull arm)

Max. 1200mm / 47.2"  Min. 550mm / 21.65"(push arm)

Max. Opening Angle 120 degrees
Environment Temp.  -20C to 50C,  -4F to 122F


Wiring Diagram

wiring diagram for Olide120BB with electric strike and push button
